Apache with SSL and http redirection to https on Ubuntu

The TLS (transport layer security) and its predecessor SSL( secure sockets layer)  are the secure protocols created in order to place normal traffic in a protected, encrypted wrapper.

These protocols allow traffic to be sent safely between remote parties with secure data transfer  where  data is being intercepted and read by someone else in the middle.

In this guide, will learn how to create a self-signed SSL certificate for Apache on an Ubuntu 14.04 server.  Which will allow you to encrypt traffic from your server to client. While this does not provide the benefit of third party validation of your server's identity, it only full fills the requirements of those simply wanting to transfer information securely to the client.

Pre-requisites

Update the linux using this command

# sudo apt-get update

Install the apache if not installed

# sudo apt-get install apache2

Activate the SSL Module

Enable the module by typing

# sudo a2enmod ssl

After you have enabled SSL, you'll have to restart the web server for the change to be recognized:

#sudo service apache2 restart

Create a Self-Signed SSL Certificate

# sudo mkdir /etc/apache2/ssl

# sudo openssl req -x509 -nodes -days 365 -newkey rsa:2048 -keyout /etc/apache2/ssl/test.key -out /etc/apache2/ssl/test.crt

Generating a 2048 bit RSA private key

................+++

.............+++

writing new private key to '/etc/apache2/ssl/test.key'

/etc/apache2/ssl/test.key: No such file or directory

140611063744160:error:02001002:system library:fopen:No such file or directory:bs                                                                                       s_file.c:398:fopen('/etc/apache2/ssl/test.key','w')

140611063744160:error:20074002:BIO routines:FILE_CTRL:system lib:bss_file.c:400:

root@osticket:~# mkdir /etc/apache2/ssl

root@osticket:~# sudo openssl req -x509 -nodes -days 365 -newkey rsa:2048 -keyout /etc/apache2/ssl/test.key -out /etc/apache2/ssl/test.crt

Generating a 2048 bit RSA private key

.+++

..................+++

writing new private key to '/etc/apache2/ssl/test.key'

-----

You are about to be asked to enter information that will be incorporated

into your certificate request.

What you are about to enter is what is called a Distinguished Name or a DN.

There are quite a few fields but you can leave some blank

For some fields there will be a default value,

If you enter '.', the field will be left blank.

-----

Country Name (2 letter code) [AU]:IN

State or Province Name (full name) [Some-State]:Telengana

Locality Name (eg, city) []:Hyderabad

Organization Name (eg, company) [Internet Widgits Pty Ltd]:test

Organizational Unit Name (eg, section) []:helpdesk

Common Name (e.g. server FQDN or YOUR name) []:helpdesk.test.com

Email Address []:test@xyz.com

Configure Apache to Use SSL

# vi /etc/apache2/sites-enabled/default-ssl.conf

<VirtualHost 192.168.0.1:443>

     DocumentRoot /var/www/

     SSLEngine on

     SSLCertificateFile /etc/apache2/ssl/apache.crt

     SSLCertificateKeyFile /etc/apache2/ssl/apache.key

</VirtualHost>

Activate the SSL Virtual Host

# sudo a2ensite default-ssl.conf

# service apache2 restart

This should enable your new virtual host, which will serve encrypted content using the SSL certificate you created.

No w can open any browser of our choice and check https://your-ip-address

To Redirect http to https 80 - 443

Comment to  <virtual host *:80>  section and add

# vi /etc/apache2/apache2.conf

<VirtualHost *:80>

         ServerName 192.168.87.138

         Redirect /scp https://192.168.87.138/scp

         DocumentRoot /var/www/html/osticket/upload

</VirtualHost>

#<VirtualHost *:80>

#    ServerName 192.168.87.138

#    DocumentRoot /var/www/html/osticket/upload

#</VirtualHost>

No w can open any browser of our choice and check http://your-ip-address it will automatically redirect the browser to https://your-ip-address
